Product Details:
Payment & Shipping Terms:
|
Blade Diameter: | 10inch ~ 48inch, Up To 118inch | Dimensions: | 250mm ~ 1200mm, Up To 3000mm |
---|---|---|---|
Power Source: | Electricity | Saw Type: | Circular Saw |
Application: | Stone Saw |
HTS: 8202390000
Core Materials: steel
Category: segmented saw blade
Sintered processing methods: Silver Brazed
Features:
1. It can be used for cutting of granite, marble, limesone, concrete, and many other materials;
2. The high frequency eletrical brazeing and touch segment design provides the exceptional performance and high productivity;
3. It can be applied to a variety of large cutting machines; due to the good core materials, the blade would not be easily deformed during use;
4, Diamond segments with diamond particles and metal powders would be connected with the core materials through Silver Brazed process, which would improve the strength of the segments and bring a solid & stable segments, to avoid some accidental injuries.
Typical models & specifications for reference:
ITEM NUMBER | OUTER DIAMETER(D) | INER DIAMETER(D) | SEGMENT HEIGHT (mm) | ||
INCHES | METRIC (mm) | INCHES | METRIC (mm) | ||
DSBB050250 | 10 | 250 | 1/1.15/2 | 25/30/50 | 8/10 |
DSBB050300 | 12 | 300 | 1/1.15/2 | 25/30/50 | 8/10 |
DSBB050350 | 14 | 350 | 1/1.15/2 | 25/30/50 | 8/10 |
DSBB050400 | 16 | 400 | 1/1.15/2 | 25/30/50 | 8/10 |
DSBB050450 | 18 | 450 | 1/1.15/2 | 25/30/50 | 8/10 |
DSBB050500 | 20 | 500 | 1/1.15/2 | 25/30/50 | 8/10 |
DSBB050600 | 24 | 600 | 1/1.15/2 | 25/30/50 | 8/10 |
DSBB050700 | 28 | 700 | 2/3.14/4 | 50/80/100 | 8/10 |
DSBB050750 | 30 | 750 | 2/3.14/4 | 50/80/100 | 8/10 |
DSBB050800 | 32 | 800 | 2/3.14/4 | 50/80/100 | 8/10 |
DSBB050900 | 36 | 900 | 2/3.14/4 | 50/80/100 | 10/12 |
DSBB051000 | 40 | 1000 | 2/3.14/4 | 50/80/100 | 10/12 |
DSBB051200 | 48 | 1200 | 2/3.14/4 | 50/80/100 | 10/12 |
Note: the arbor size, segment height, thickness can be customized according to the buyers' requirements. The max outdiameter can be up to 118inch (3000mm)
